Everything that is filtered out of the air is captured in a drip well and can be either manually drained or automatically drained whenever the fluid hits a certain point. However, we are forcing the supply air through a sintered polyethene filter, either 40 or 5 microns in size, to filter out moisture and very small particulates from the supply air. The regulating principles are the same here as they are for all air pressure regulators. This is essential when it comes to protecting expensive lab equipment, valve positioners, or I/P transducers. The purpose of a filter regulator is to clean the air line of moisture and particulates all while reducing air pressure to a setpoint. Some of the more common applications of these units include medical OEMs, web tensioning, ventilators, calibration standards, and microfluidics.įilter Regulators are vital air preparation devices when it comes to protecting your sensitive downstream equipment. All of our precision air pressure regulators have a sensitivity less than 1” water column or about 0.036 PSI. The same principle is used in the Type 700 however, we are able to achieve the constant bleed without the use of a bleed screw.
We do this by constantly bleeding a small amount of air, which never lets the diaphragm settle. We are able to achieve this high level of sensitivity by keeping the diaphragm of the unit in a reactive state. That means that if the output pressure differs from the set pressure by about 0.0045 PSI, the unit will make a correction to bring output pressure back to the setpoint. The Type 100, for example, has a sensitivity of 1/8” water column. You can think of sensitivity as a regulator’s ability to react to changes in air pressure relative to the unit’s set point. The thing that sets precision regulators apart from general use regulators is mainly their accuracy and sensitivity. The Type 100, one of our first models and approved for use in oxygen ventilators in 1989, is still widely used today. When ControlAir first got started, we built our business around manufacturing precision air pressure regulators. Precision Air Pressure Regulators are ControlAir core product line.
